set1. 8-12 mm glass
2. Max. weight 90 kg
3. Recommended plate width: 850-950 mm
4. Max. plate width: 1000 mm
5. Opening force: not adjustable
6. Models with and without locking at 90° available.
7. Max. opening angle 150°.
8. 2-zone adjustment of door opening and closing speed
9. Zero position adjustment ±4° from axle.
10. Rotation axis positioning ±3 mm.
11. Fitting position head not adjustable.
